Wireless ISP Network IP Scheme

For those of you starting out in the WISP field here is a good overview of a scalable Ip scheme for your WISP network. There are some caveats to this, which we will discuss later. This does not address IPV6, I have done some articles on IPv6 in the past that addresses IPV6.

Some benefits of this scheme
1.Logically separates equipment into groups.
2.Cookie-Cutter design. Fast time to depoyment
3.Easy to train on for techs and office
4.Scriptable

This following scheme uses private IP space for infrastructure. This scheme does not address end-user addressing. More on this in a later guide.

For each tower I route a /16 out of the 10.0.0.0/8 IP space. For example my first tower is
10.1.0.0/16 . Your first thought is that is alot of IP space. Yes it. However, it is private IP space and you can use as much as you want. The second thought is you can only use this scheme 255 times. Yes this is true. How many WISPs are growing beyond 255 towers. Most of the wisps I know are in the 100 tower sweet spot. There are larger and smaller wisps.

So lets break this down. We are using tower 1 as an example.

Wired Infrastrudture
1-Not used due to default being VLAN 1 on most devices. Quarantine vlan
10.1.2.0/24

2- Power and UPSes
10.1.2.0/24

3- Switches and routers
10.1.3.0/24

5-9 reserved for  future uses

Backhaul Management VLANS

10-19
10.1.10.0/24 – Backhaul 1
10.1.11.0/24 – BackHaul 2
etc.

Infrastructure Radio VLANS (tagged management)

20-29 – 2GHZ equipment
10.1.20.0/24 – First 2.4GHZ AP
10.1.21.0/24 – Send 2.4GHZ AP
10.1.22.0/24 – Third 2.4 GHZ AP Management

30-39 – 3GHZ Equipment
10.1.30.0/24 – First 3GHZ AP

40-49 – RESERVED

50-59 -5GHZ equipment

60-69 – 60GHZ equipment

70-79 – RESERVED

80-89 – 80 GHZ

90-99 – RESERVED possible IOT

Customer VLANS (untagged)

120-129 – 2GHZ equipment
10.1.120.0/24 – Customer CPE on first 2.4GHZ AP
etc.

130-139 – 3GHZ Equipment

140-149 – RESERVED

150-159 -5GHZ equipment

160-169 – 60GHZ equipment

170-179 – RESERVED

180-189 – 80 GHZ

Point to Point customers

200-299

So why so much IP space? It helps keep your routing table small.
